HumiSeal 2C51
HumiSeal 2C51 Description
- HumiSeal 2C51 is a two-component high strength, fast curing silicone encapsulating gel supplied as Parts A and B, suitable for general printed circuit board applications.
- HumiSeal 2C51 is characterized by room temperature cure and low viscosity for ease of application and contains UV tracer for ease of inspection.
- The two components of HumiSeal 2C51 are blue and yellow and turn green when mixed. HumiSeal 2C51 is RoHS Directive EU 2015/863 compliant.
Technical data of HumiSeal 2C51
| Property | Value |
|---|---|
| Density (part A&B), per ASTM D1475 | 0.97 ± 0.03 g/cm³ |
| Solids Content, % by weight per Fed-Std-141, Meth. 4044 | 99.0 % |
| Viscosity (Part A), per Fed-Std-141, Meth. 4287 | 275 ± 75 centipoise |
| Viscosity (Part B), per Fed-Std-141, Meth. 4287 | 550 ± 150 centipoise |
| VOC | 0 grams/liter |
| Drying Time to Handle per Fed-Std-141, Meth. 4061 | 10 minutes |
| Curing Condition to Reach Optimum Properties | 30 minutes @ 70°C or 60 min @ RT |
| Recommended Stripper | HumiSeal® Stripper 1090 |
| Gel Time at Room Temperature | 8-10 minutes |
| Shelf Life at Room Temperature, DOM | 12 months |
| Hardness, Shore 00 | 45-55 |
| Volume resistivity per ASTM D257 | 5.2 x 10^13 Ohms.cm (52 TΩ.cm) |
| Dielectric Strength per ASTM D149 | 434 V/mil |
"Please note that the are provided as per the specified testing methods and standards"
Application of HumiSeal 2C51
- Cleanliness of the substrate is of extreme importance for the successful application of HumiSeal 2C51.
- Surfaces must be free of moisture, dirt, wax, grease, flux residues and all other contaminants.
- Contamination under the coating could cause problems that may lead to assembly failures.
- Mixing ratio of Part A to Part B is 1:1 by volume (or weight). Prior to application, HumiSeal 2C51 Parts A and B should be thoroughly mixed until a homogenous blend is achieved. Vigorous mixing is not recommended as entraps air pockets mix.
Brushing
- HumiSeal 2C51 may be applied by brush after mixing of both parts.
- Uniformity of the film depends on component density and operator's technique.
Spraying
- HumiSeal 2C51 can be sprayed using conventional spraying equipment.
- Spraying should be done in an environment with adequate ventilation so that the vapour and mist are carried away the operator.
Storage
- HumiSeal 2C51 Parts A and B should be stored away excessive heat or cold, in tightly closed containers.
- HumiSeal 2C51 may be stored at temperatures not exceeding 38 °C (100 ºF).
Caution Application of HumiSeal 2C51
This products should be carried out in accordance with local and National Health and Safety regulations. Use only in well-ventilated areas to avoid inhalation of mist or spray. Avoid contact with skin and eyes.
